Product Details

Integrated Temperature & Pressure Sensor (Sub-Industrial Grade)

All-in-One · IP68 Submersible · UART Output
Housing Material
All-metal housing (304 stainless steel)
Protection Rating
IP68 (fully submersible)
Pressure Range
0 ~ 500 kPa
Temperature Range (Measurement)
-10°C ~ +70°C
Accuracy
±0.5% FS (Full Scale)
Pressure Type
Gauge (S)
Supply Voltage & Current
3.1 ~ 3.6 VDC, ≤2 mA
Operating Temperature
-30°C ~ +70°C
Power Consumption
≤10 mW
Explosion-proof Rating
Ex ia IIC T5 Gb (Intrinsically Safe)
Service Life
≥10 years
Communication
UART (Serial)
