Laser Pan-Tilt Unit

Brand: tlcssk

Model: {{ product.model }}

{{ variable.name }} : {{ variable.values[selectedVariantsIndex[variable_index]].name }}

Product Details

Laser Pan-Tilt Unit

Remote Methane Detection · Ex d IIC T6 · IP68 · 1080p Camera

Target Gas

Methane (CH₄)

Camera

Full HD 2.1 Megapixel (1080p)

Measurement Principle

Tunable Diode Laser Absorption Spectroscopy (TDLAS)

Altitude

< 2000 m (atmospheric pressure 80–110 kPa)

Detection Laser

Infrared, invisible, Class I (eye-safe)

Operating Temperature

-35°C ~ +65°C

Pointer Laser

Green, Class I (do not stare into beam or view with optical instruments)

Storage Temperature

-40°C ~ +70°C

Static Detection Limit

5 ppm·m

Operating Humidity

< 90% RH (non-condensing)

Sampling Frequency

100 kHz

Data Interfaces

RS-485, Ethernet, ALARM output

Response Time

≤ 0.05 s

Power Supply

220 V AC

Measuring Range

0 ~ 100,000 ppm·m

Typical Power Consumption

< 60 W

Dimensions (L×W×H)

520 mm × 305 mm × 400 mm

Measurement Error

< ±0.01% FS

Weight

30 kg

Repeatability

< ±1%

Pan/Tilt Motion Range

Pan: ±360°, Tilt: ±90°

Explosion-proof Rating

Ex d IIC T6 Gb

Pan/Tilt Speed

Pan: 0.1° ~ 40°/s, Tilt: 0.1° ~ 30°/s

Ingress Protection

IP68 (fully submersible)

Preset Positions

999
