Vehicle-mounted Laser Methane Inspection Instrument

Electric Gas Patrol Vehicle (Methane)

Gas Patrol Vehicle (Methane)

Robot Dog Laser Methane Inspection

UAV Inspection (Multispectral Imaging)

Connected Mobile Alarm

Brand: tlcssk

Model: {{ product.model }}

{{ variable.name }} : {{ variable.values[selectedVariantsIndex[variable_index]].name }}

Product Details

Portable Combustible Gas Monitor · RS485/4-20mA · IP66

Measuring Range

0 ~ 100% LEL

Typical Accuracy

≤ ±2% FS

Sampling Method

Diffusion

Power Supply

DC 24V (optional Li-polymer battery: 5Ah / 10Ah / 30Ah / 50Ah)

Operating Environment

Temp: -20°C ~ +55°C (extreme -40°C ~ +70°C); Humidity: 10~95% RH

Signal Output

RS485 (Modbus RTU) & 4-20 mA (3-wire)

Alarm Type

Audible + visual strobe (optional), 1-3 relay dry contact outputs

Dimensions (L×W×H)

346 mm × 275 mm × 90 mm (max)

Weight

Approx. 5 kg

Ingress Protection

IP66 (dust-tight, strong water jets)
